Technical data COBRA Mill 5M

X;Y;Z axis stroke 100 x 135 x 100 mm
A axis stroke -90/+30°
B axis stroke 360°
Feed rate Max. 6000 mm/min
Position feed Max. 8000 mm/min
Repeatability 0,008 mm
Min. setting unit 0,001 mm
Rounds dimensions 100 mm
Distance Holder centre - Spindle 75 mm
Max. E-max Block length 40 mm
AC Servomotors 100/200  Watt
AC Servodrivers 200 Watt
HF Spindle Jaeger 60000 rpm / 230 Watt
Optional HF Spindel 80000 rpm / 280 Watt
Tool length / Ø max.  42~50 mm / 3,0 mm
Number of tools 6 pcs
Power connection +/- 5% 230 V
Max. connected load 3,2 kVA
Compressed air connection 300 l/min at 6,5 bar
Dimension W;D;H 780 x 820 x 1700 mm
Weight 275 kg

Controller:

OSAI/MB 10/510i HSM
Visualisation PC Software
5 axis simultaneous
Tool correction
40 MB working memory
OS Wire I/O Board
Network
Teleservice
10 Work coordinates
SMS Worker information

Wet-setup:

Fine filter / filter bag
manuel changeover
Flow rate detection
Strong rinsing pump
